Widely used in wind energy shipbuilding and aviation fields.
★Product Description★
Double side nylon film is a multi-layer composite special film. It has high strength and high elongation, and can directly contact resin. It is mainly used for normal temperature molding, vacuum injection and pre-compaction of composite materials.
★Product Specifications★
|
Material |
PA/PE |
|
Structure |
9 Layer Co-Extrusion |
|
Thickness |
55um, 65um, 75um, Support customer customization |
|
Width |
Up to 2400mm, Support customer customization， |
|
Appearance |
Smooth film / embossed film |
|
Color |
Blue, Green, Red, Yellow, Support customer customization |
|
Temp Range |
Below 150 Degree |
|
Tensile Strength |
≥40 Mpa |
|
Elongation |
≥400% |
|
Certification |
ISO, SGS, FDA, ROHS, BPA free |
|
Feature |
Low Oxygen Transmission Rate, Low Water Vapour Transmission Rate, High Puncture Resistance, High temperature resistance |
width and length can be customized according to customer requirements
★Product storage★
The double side nylon film shall be stored in a dry and dark place to avoid exposure to sunlight. Storage conditions: humidity 65 ± 20% RH, temperature 5-30 ℃. The place where the vacuum bag film is placed shall be smooth, and sharp objects shall be removed to avoid puncturing the film. Handle with care. When using the product, pay attention to the protection of the bag film surface. Do not place or touch sharp objects to avoid piercing the film. The storage life shall not exceed 2 years.
★Applications★
Widely used in wind energy shipbuilding and aviation fields.
★FAQ★
Q1. Are you a factury or trade company?
A1. We are professional manufacturer of multi-layer coextrusion high barrier composite film, which has over thirty years' experience in this field.
Q2. what's your product equipment?
A2. 11 layer WH blown film line from German,
9 layer Macchi blown film line from Italy,
9 layer BE blown film line from Canada,
7 layer Macchi blown film line from Italy,
Q3.Can you provide sample?
A3. Yes, the sample is free, we will be very grateful if you can provide shipping cost.
Q4. How do you test your product?
A4.Our company has a dedicated laboratory, we will have a professional product testing, we can provide technical data sheet for each product
Q5. What should be provided when placing orders?
A5.The material, structure, size, thickness, width, length, and order quantity.
